36volt 18AH 65km+ Mileage Electric Cycle Lithium Battery Pack

Description

High-Performance Lithium-Ion Battery for E-Bikes and E-Cycles

Product Overview:

This Lithium-Ion battery is designed for use with both Hub Motors and DC Gear Motors, offering a reliable power solution for your e-bike or e-cycle. Featuring a Battery Management System (BMS), this battery provides essential protection from overcharging, deep discharge, and overheating, ensuring a safe and long-lasting performance. It’s optimized to work seamlessly with both 250W and 350W motors while being significantly lighter than conventional lead-acid batteries.

This battery offers high power output, extended range, and a lifespan of up to 3 years, making it an excellent choice for e-cycle enthusiasts looking for efficiency and reliability.

Key Features:

• Motor Compatibility: Ideal for both 250W and 350W e-bike motors

• Battery Type: Advanced Lithium-Ion with integrated BMS (Battery Management System)

• Protection Features: Overcharge protection, deep discharge protection, and thermal management

• Lightweight: Lighter than traditional lead-acid batteries for improved efficiency

• Long-Lasting: Battery lifespan of up to 3 years

• Charge Cycles: Supports 1000–1200 charge cycles

• High Backup Capacity: Provides excellent range and backup for long-distance rides

Performance Data:

• Range with 250W Motor:

  • Full Charge Range: Approx. 65 km (Tested with a 55 kg rider)

• Range with 350W Motor:

  • Full Charge Range: Approx. 65 km (Tested with a 55 kg rider)

Battery Specifications:

• Voltage: 36V

• Capacity: 21Ah (21,000mAh)

• Max Discharge Current: 20A

• Cell Type: DMEGC 2600mAh 3C EV-grade lithium-ion cells

• BMS Protection: 10s20A with heat sink protection

• Charge Cycles: Approx. 1000–1200 full charge cycles

• Discharge/Charging Wires: 2.5 sqmm wire (same port for charging and discharging)

• Max Capacity: 21Ah (21,000mAh)

Charging Specifications:

• Charger Voltage: 42V

• Charger Current: 3A / 5A

• Important Notice: Only use a lithium-ion charger. Do not use a lead-acid battery charger.

Dimensions & Weight:

• Battery Dimensions (Standard Model):

  • Length x Width x Height: 21 x 21 x 8 cm

  • Weight: 4.2 kg

• Battery Dimensions (Compact Model):

  • Length x Width x Height: 8 x 8 x 29 cm

  • Weight: Approx. 2.5 kg

Warranty Information:

• Warranty: This battery comes with a 2-year warranty.

• For full details, please refer to our Warranty Policy page.

Package Includes:

• 1 x Lithium-Ion Battery

• 1 x Battery Socket

This Lithium-Ion battery is a high-performance solution for powering your e-bike or e-cycle. With its light weight, advanced protection features, and long battery life, it is an excellent choice for riders who demand efficiency and reliability.
